Product Description

Due to its specially adapted sealing system this drill allows both wet drilling (for use on concrete and brick) and dry drilling (masonry). Water-cooling and dust extraction can thus be achieved without the addition of any special accessories.

This very powerful and flexible hand-held core drill motor has 3 speed gearing to accommodate a large range of Core Drill sizes and a leveling aid allows pinpoint accuracy for horizontal or vertical drilling. Its safety and operational features include optimal gear lubrication; clutch overload protection, metal machine casings and the Intellitronic power feed control system.The Intellitronic electronic start-up system uses a microprocessor to ensure a smooth build-up of drilling speed and also guards against overload in use by causing the motor to pulsate until there is a return to safe operating conditions.

Technical Spec

• Drilling Ø (mm) In drill stand (concrete) 15-130
• Hand held (concrete) 15-80
• Hand held (masonry) 20-150
• Nominal Power (W) 1600
• Output Power (W) 1100
• No-load Speed (1/min) 970/2330/4830
• Load Speed (1/min) 580/1400/2900
• Weight (kg) 6.3
• Length (mm) 420
• Voltage (V) 110
• Tool Fixture 1¼” UNC/m
• Mounting Neck 60mm
• Decibel Level (dB(A)) 86
• Vibration Level (m/s2) <2.5
